Rixson Model 5014x554 Thin Slab Center Hung Floor Closer Package
|
|
Our Price: Starting at $741.00
Manufacturer: Rixson
Model: 5014BCx554
Specify Model Options
| |
| |
| |
|
Rixson Model 5014 x 554
Single Acting Center Hung Thin Slab Floor Closer w/554 Arm - Complete Package
Application
Single Acting
Interior Doors
Weight to 250 lbs.
Door Width to 42"
ANSI C06021
Spring Size
Size 4
Hold Open
Specify Non-Hold Open w/Back-Check (NHO) or Automatic Hold Open w/Back-Check (90A)
Handing
Specify LH or RH
Finish
Specify 605, 606, 612, 613, 625 or 626
Features
Complete package includes Rixson Model 5014 Closer Body, 340 Top Pivot, Bottom Arm Package, Floor Plate Package and Cement Case
-
Identical to Model 5014 except:
-
Arm is designed to eliminate visible adjusting screws on face of door
-
Arm bolt locks arm to closer spindle - adjustments made through heel of door
-
Shims cannot be used with this model
-
Size 4 - 42" Door Width
-
Available non-hold open (NHO) or automatic hold open at 90° (90A)
-
Will swing as far as frame trim will permit
-
Not allowed for fire rated doors
-
Applied stop required (see Rixson Model 60131 Applied Stop)
-
Closer body available less all parts (-LAP)
Listed specifications for models stocked and available for immediate shipment from ePivots online store. Please call for fire-rated, special finish or other configuration requirements.
 Downloads
|
MSRP: $112.00
Our Price: $67.20
Center Hung Top Pivot
|
MSRP: $84.00
Our Price: $50.40
Floor Plate for Rixson Model 50 Series Concealed Floor Closers
|
Our Price: Starting at $505.80
Single Acting Center Hung Thin Slab Floor Closer Body - Size 4
|
MSRP: $84.00
Our Price: $50.40
Cement Case for use with Rixson Model 50 & 51
|
MSRP: $112.00
Our Price: $67.20
554 Arm Package for use with Rixson Model 28 & 50 Series Closers
| |
|
|
