Rixson Model 5104 Concealed Floor Closer Package
|
|
Our Price: Starting at $760.20
Manufacturer: Rixson
Model: 5104BC
Specify Model Options
| |
| |
| |
|
Rixson Model 5104
3/4" Offset Hung Thin Slab Floor Closer - Size 4 - Complete Package
Application
Single Acting
Interior Doors
Weight to 250 lbs.
Door Width to 42"
ANSI C06041
Spring Size
Size 4
Hold Open
Specify Non-Hold Open w/Back-Check (NHO) or Automatic Hold Open w/Back-Check (90A)
Handing
Specify LH or RH
Finish
Specify 605, 606, 612, 613, 625 or 626
Features
Complete Package includes Rixson Model 5104 Closer Body, 180 Top Pivot, Bottom Arm Package, Floor Plate Package and Cement Case
-
Interchangeable spindle adapters
-
Size 4 spring - 42" door width (Also available in size 3, see Rixson Model 5103)
-
Available non-hold open (NHO) or automatic hold open at 90° (90A)
-
Vertical door adjustment
-
Cycolac cement case
-
Model M19 Intermediate Pivot recommended, sold separately
-
Doors up to 90" in height should use one intermediate pivot. Each additional 30" warrants another intermediate pivot.
-
Closer body available less all parts (-LAP)
Listed specifications for models stocked and available for immediate shipment from ePivots online store. Please call for fire-rated, special finish or other configuration requirements.
 Downloads
|
MSRP: $167.00
Our Price: $100.20
3/4" Offset Top Pivot
|
Our Price: Starting at $505.80
3/4" Offset Thin Slab Floor Closer Body - Size 4, Single Acting
|
MSRP: $84.00
Our Price: $50.40
Cement Case for use with Rixson Model 50 & 51
|
MSRP: $87.00
Our Price: $52.20
3/4" Offset Arm Package for use with Rixson Model 25 & 27
|
MSRP: $86.00
Our Price: $51.60
Floor Plate for Rixson Model 51 Series Concealed Floor Closers
| |
|
|
